Bulk density: 6.05g/cm³
Customized shape and size
PRODUCT DETAILS
Product Description
Zirconia ceramic introduction:
Zirconia ceramic (ZrO₂) is an advanced technical ceramic material known for its exceptional combination of strength, toughness, and wear resistance. It exists in several crystal phases, with the stabilized forms being widely used in engineering applications.
Zirconia ceramic performance:
It offers exceptional fracture toughness (8–12 MPa·m¹/²) and bending strength (900–1,200 MPa). The material also provides good thermal insulation and reliable performance up to 1,000°C.
Zirconia ceramic Key Features:
Premium Zirconia Material
Precision Hole Design
Industrial-Grade Wear Resistance
Corrosion Resistance & Insulation
Zirconia ceramic Typical Applications:
As a versatile industrial ceramic component, it is widely used in precision machinery, fluid control systems, electronic devices, and chemical processing.
TECHNICAL SPECIFICATION OF ZIRCONIA CERAMIC
项目
Item
单位
Unit
氧化锆
Zirconia (ZrO2)
体积密度
Bulk density
g/cm3
6.05
吸水率
Water absorption
%
0
抗折强度
Flexural strength
MPa
1000
硬度
Hardness vickers
HV
1300
弹性模量
Elastic modulus
GPa
205
线性膨胀系数
Linear expansion coefficient
(20-500℃) 10-6/K
10
导热系数
Thermal conductivity
W/(m·K)
＜2
