High Temperature Resistant Silicon Carbide SiC Ceramic Graphite Crucible with Quartz Sleeve for Induction Furnace

High Temperature Resistant Silicon Carbide SiC Ceramic Graphite Crucible


Availability:

Quantity:

Inquire Add to Basket

Customized appearance size

High-temperature sintering

20 years export experience
8 Trademarks 40 Patents
Design & Research
Cooperated with Global 500 enterprises
Certificates:ISO、ROHS、CE etc.

PRODUCT DETAILS

Product Description

	Silicon Carbide ceramic crucibles: Designed for Melting Gold, Silver, Copper, Brass, Aluminum, and more Rated to withstand temperature up to 1499°F - 2900° F (800°C- 1600°C) Excellent thermal shock resistance, electrical conductivity and thermal conductivity.
Graphite Crucible : Good wear resistance, strong lubrication performance and long service life. High purity, high density, high mechanical strength, strong chemical stability. Designed to use with Fuel and Medium or High-Heat Induction Furnaces and Kilns.
	SiC ceramic crucibles Features: 1.High strength graphite strength increases 2.High temperature resistance 3.Good heat shock resistance 4.Anti-oxidation 5.Strong corrosion resistance to acid and alkali liquid
SiC ceramic crucibles Features: 1.Abrasion resistance 2.Good conductivity and thermal efficiency. 3.Excellent chemical stability 4.Small thermal expansion coefficient 5.Easy to clean 6. High Purity 7. High machining capabilities

Technical Data of Silicon Carbide (SIC)

项目 Item	单位	常压烧结碳化硅 SSIC	反应烧结碳化硅 RBSIC/SISIC	重结晶烧结碳化硅 RSIC
项目 Item	UNIT	DATA	DATA	DATA
最高使用温度 Max temperature of Application	℃	1600	1380	1650
密度 Density	g/cm³	>3.1	>3.02	>2.6
气孔性 Open Porosity	%	<0.1	<0.1	15%
抗弯强度 Bending Strength	Mpa	>400	250(20℃)	90-100(20℃)
抗弯强度 Bending Strength	Mpa		280(1200℃)	100-120(1100℃）
弹性模量 Modulus of Elasticity	Gpa	420	330(20℃)	240
弹性模量 Modulus of Elasticity	Gpa		300(1200℃)
热传导系数 Thermal Conductivity	W/m.k	74	45(1200℃)	24
热膨胀系数 Coefficient of Thermal Expansion	K^-1x10^-6	4.1	4.5	4.8
维式硬度 Vickers Hardness HV	Gpa	22	20
耐酸碱度 Acid Alkaline-proof		优（excellent）	优（excellent）	优（excellent）

备注：以上数据仅供参考。

Note:The above data is only for your reference.
