Product Description
| Silicon Carbide Ceramic Sleeve Introduction: Silicon carbide ceramics have excellent performance of high working temperature, mechanical strength, pressure ， large thermal conductivity, thermal shock resistance and chemical corrosion resistance etc.. |
SiSiC Ceramic Tube Application: 1. The electronic and electrical industry: packaging materials for large-scale integrated circuits. 2. High temperature and wear-resistant components: high-temperature bearings, bulletproof plates, nozzles | |
| Advantages of RSiC Silicon Carbide Sleeve 1. Low density 2. high mechanical strength, good rigidity 3. high temperature resistance, small thermal expansion coefficient |
Silicon carbide material characteristics 1. High hardness 2. High wear resistance 3. Corrosion resistance 4. Good thermal shock resistance | |
Technical Data of Silicon Carbide (SIC)
项目 Item | 单位 | 常压烧结碳化硅 SSIC | 反应烧结碳化硅 RBSIC/SISIC | 重结晶烧结碳化硅 RSIC |
UNIT | DATA | DATA | DATA | |
最高使用温度 Max temperature of Application | ℃ | 1600 | 1380 | 1650 |
密度 Density | g/cm3 | >3.1 | >3.02 | >2.6 |
气孔性 Open Porosity | % | <0.1 | <0.1 | 15% |
抗弯强度 Bending Strength | Mpa | >400 | 250(20℃) | 90-100(20℃) |
Mpa | 280(1200℃) | 100-120(1100℃） | ||
弹性模量 Modulus of Elasticity | Gpa | 420 | 330(20℃) | 240 |
Gpa | 300(1200℃) | |||
热传导系数 Thermal Conductivity | W/m.k | 74 | 45(1200℃) | 24 |
热膨胀系数 Coefficient of Thermal Expansion | K-1x10-6 | 4.1 | 4.5 | 4.8 |
维式硬度 Vickers Hardness HV | Gpa | 22 | 20 | |
耐酸碱度 Acid Alkaline-proof | 优（excellent） | 优（excellent） | 优（excellent） |
备注：以上数据仅供参考。
Note:The above data is only for your reference.
Company Profile
Packaging & Shipping
Packing Details | We will packing by professional export packing,safety against breakage, finally into the wooden cases/ carton/pallet or customized package. We have ERP authentication. |
Delivery Details | We can deliver by SEA,air,rail transportation,the China-Europe Railway Express etc. TNT, DHL,UPS, FEDEX, EMS，S.F EXPRESS etc. |
| 1. Sample service | 2. Optimal price | 3. Customized logo |
| 4. Fast feedback | 5. Customized size | 6. Safety package |
| 7. ISO9001 | 8. Aftersale service | 9. Low procurement risk |
