Customized Alumina Irregular Tube Glazed Al2O3 Ceramic Threaded Part

Customized Alumina Tube Glazed Al2O3 Ceramic Threaded Part


Availability:

Quantity:

Inquire Add to Basket

20 years export experience
8 Trademarks、40 Patents
Design & Research
Cooperated with Global 500 enterprises
Certificates:ISO、ROHS、CE etc.

Maximum Use Temperature:1450°C

Flexural strength(20° C):358(52) MPa (psi x 103)

Density:3.6 g/cm³

PRODUCT DETAILS

Product Description

	Advantages of Alumina Tube: Wear & abrasion resistant High compressive strength High mechanical Strength Resists strong acid and alkali attack at high temperatures Excellent electrical insulation properties Decent thermal conductivity
Application of Al2O3 Threaded Part: 1. Furnace liner tubes 2. Thread and wire guides 3. Electronic substrates 4. Abrasion resistant tube and elbow liners 5. Thermometry sensors 6. Laboratory instrument tubes and sample holders
	Alumina Ceramic Irregular Tube: Aluminum oxide ceramics have high hardness, high wear resistance, excellent electrical insulation and chemical stability, good heat resistance, excellent dielectric properties, high thermal conductivity, and excellent heat dissipation.
Ceramic Threaded Part: Specifically used for high-temperature and high-voltage insulation parts, circuit substrates, plungers, etc. As the main representative of precision ceramic materials, it is widely used and mainly used in industries such as semiconductors, electrical appliances, textile, etc

Alumina Purity	92%	95%	96%	99%	99.6%
颜色 Color	White	White	White	Ivory White	White
体积密度 Volume density(g/cm3)	3.45	3.5	3.7	3.75	3.9
吸水率 Water Absorption	0	0	0	0	0
抗弯强度 Flexural Strength	300Mpa	300Mpa	320Mpa	330Mpa	330Mpa
维氏硬度 Vickers hardness	1300	1400	1400	1800	1800
介电常数 Dielectric Constant (at 1MHZ 25℃)	10	10	10	10	10
弹性模量 Modulus of elasticity	350Gpa	350Gpa	350Gpa	370Gpa	370Gpa
热导率 thermal conductivity (30℃)	18W/M.K	24W/M.K	24W/M.K	25W/M.K	28W/M.K
体积电阻率 Volume resistivity	10^14Ω•cm	10^14Ω•cm	10^14Ω•cm	10^14Ω•cm	10^15Ω•cm
介电强度 Dielectric strength	20KV/mm	20KV/mm	20KV/mm	20KV/mm	30KV/mm

Company Profile

silicon carbide ceramic oil cup

Packaging & Shipping

Packing Details

We will packing by professional export packing,safety against breakage, finally into the wooden cases/ carton/pallet or customized package. We have ERP authentication.

Delivery Details

We can deliver by SEA,air,rail transportation,the China-Europe Railway Express etc.

TNT, DHL,UPS, FEDEX, EMS，S.F EXPRESS etc.

Our Services

What we can do for you:

1. Sample service	2. Optimal price	3. Customized logo
4. Fast feedback	5. Customized size	6. Safety package
7. ISO9001	8. Aftersale service	9. Low procurement risk
