Product Description
| SiC Taper Bushing： High hardness, wear resistance and low friction |
Silicon carbide product advantages: 1. High temperature resistance 2. Low heat loss 3. No dust, fine grinding polishing 4. Custom specifications, support proofing | |
| SiC ceramics properties: SiC ceramics structural support have excellent room temperature mechanical properties, but also high temperature mechanical properties (strength, creep resistance, etc.) is the best known ceramic materials. |
| SSIC ceramic ring features: 1. High Temperature resistance, SiSiC disc can withstand 1380C, SSiC support can withstand 1600C at most. 2. High strength and excellent hardness. 3.Tight tolerance and good surface roughness. | |
项目 Item | 单位 | 常压烧结碳化硅 SSIC | 反应烧结碳化硅 RBSIC/SISIC | 重结晶烧结碳化硅 RSIC |
UNIT | DATA | DATA | DATA | |
最高使用温度 Max temperature of Application | ℃ | 1600 | 1380 | 1650 |
密度 Density | g/cm3 | >3.1 | >3.02 | >2.6 |
气孔性 Open Porosity | % | <0.1 | <0.1 | 15% |
抗弯强度 Bending Strength | MPa | >400 | 250(20℃) | 90-100(20℃) |
MPa | 280(1200℃) | 100-120(1100℃） | ||
弹性模量 Modulus of Elasticity | GPa | 420 | 330(20℃) | 240 |
GPa | 300(1200℃) | |||
热传导系数 Thermal Conductivity | W/(m·K) | 74 | 45(1200℃) | 24 |
热膨胀系数 Coefficient of Thermal Expansion | K-1x10-6 | 4.1 | 4.5 | 4.8 |
维式硬度 Vickers Hardness HV | GPa | 22 | 20 | |
耐酸碱度 Acid Alkaline-proof | 优（excellent） | 优（excellent） | 优（excellent） |
Company Profile
Packaging & Shipping
Packing Details | We will packing by professional export packing,safety against breakage, finally into the wooden cases/ carton/pallet or customized package. We have ERP authentication. |
Delivery Details | We can deliver by SEA,air,rail transportation,the China-Europe Railway Express etc. TNT, DHL,UPS, FEDEX, EMS，S.F EXPRESS etc. |
| 1. Sample service | 2. Optimal price | 3. Customized logo |
| 4. Fast feedback | 5. Customized size | 6. Safety package |
| 7. ISO9001 | 8. Aftersale service | 9. Low procurement risk |
