Product Description
| Alumina ceramic: Aluminium Oxide, Al2O3 is the most widely applied and cost effective technical ceramic material. |
Alumina part: Good thermal conductivity, high insulation strength, high electrical resistivity, low dielectric loss, with a dielectric constant generally between 8-10; Lightweight, the density of alumina ceramics is half that of steel, which can reduce equipment load. | |
| Application of Alumina Ceramic: It is specifically used for high temperature and high pressure insulation parts, high temperature devices, mechanical wear-resistant parts, sealing rings, plungers, etc. |
Al2O3 Ceramic Features： • Increased life in service • High quality ground surface finish • High flexural strength values • Non-electrically conducting • high temperature resistance | |
| Alumina | |||||
Alumina Purity | 92% | 95% | 96% | 99% | 99.6% |
Color | White | White | White | Ivory White | White |
Volume density(g/cm3) | 3.45 | 3.5 | 3.7 | 3.75 | 3.9 |
Water Absorption | 0 | 0 | 0 | 0 | 0 |
Flexural Strength | 300Mpa | 300Mpa | 320Mpa | 330Mpa | 330Mpa |
Vickers hardness | 1300 | 1400 | 1400 | 1800 | 1800 |
Dielectric Constant (at 1MHZ 25℃) | 10 | 10 | 10 | 10 | 10 |
Modulus of elasticity | 350Gpa | 350Gpa | 350Gpa | 370Gpa | 370Gpa |
thermal conductivity (30℃) | 18W/M.K | 24W/M.K | 24W/M.K | 25W/M.K | 28W/M.K |
Volume resistivity | 10^14Ω•cm | 10^14Ω•cm | 10^14Ω•cm | 10^14Ω•cm | 10^15Ω•cm |
Dielectric strength | 20KV/mm | 20KV/mm | 20KV/mm | 20KV/mm | 30KV/mm |
