PRODUCT DETAILS
Product Description
Ceramic ignitior:
1)Ceramic Insulator Body: 95% Alumina, Steatite with glazed or no glazed layer .
2) Electrode Pin/Rod: OCr25Al5, SUS304, Ni80Cr20,KanthalA1, etc.
3)Bracket: Steel-Nickel Plated, Steel-ZINC Plated, Steel- Copper Plated etc.
Ceramic ignition:
1.Anti-heat,corrosion resistance, anti-high voltage,stable electrical property,and high insulation functions. 2.Output voltage: Min. 16 ~25kv 3.Life time (using life)200,000 times.
Advantages of spark plug ignition:
They are commonly used in spark plug, ignition electrode of glas appliances accessories, combustion machine, boiler and various of booster ignition devices.
Spark plug
Alumina spark plug insulators are mainly made of 95% alumina ceramic, which is a major engineering material.
Alumina Purity
92%
95%
96%
99%
99.6%
颜色
Color
White
白色
White
白色
White
白色
Ivory White
象牙白
White
白色
体积密度
Volume density(g/cm3)
3.45
3.5
3.7
3.75
3.9
吸水率
Water Absorption
0
0
0
0
0
抗弯强度
Flexural Strength
300MPa
300MPa
320MPa
330MPa
330MPa
维氏硬度
Vickers hardness
1300
1400
1400
1800
1800
介电常数
Dielectric Constant (at 1MHZ 25℃)
10
10
10
10
10
弹性模量
Modulus of elasticity
350GPa
350GPa
350GPa
370GPa
370GPa
热导率
thermal conductivity (30℃)
18W/(m·K)
24W/(m·K)
24W/(m·K)
25W/(m·K)
28W/(m·K)
体积电阻率
Volume resistivity
1014Ω•cm
1014Ω•cm
1014Ω•cm
1014Ω•cm
1015Ω•cm
介电强度
Dielectric strength
20KV/mm
20KV/mm
20KV/mm
20KV/mm
30KV/mm
Company Profile
Packaging & Shipping
Packing Details
We will packing by professional export packing,safety against breakage, finally into the wooden cases/ carton/pallet or customized package. We have ERPauthentication.
Delivery Details
We can deliver by SEA,air,rail transportation,the China-Europe Railway Express etc.
We are mainly supplying quartz glass, cuvette, precise ceramics, porous ceramics, thick film resistor, ozone generator, metal fiber felt and we have been offering our products and services to our clients from more than 107 countries or regions.
